Product details

Flow temperature and flow pressure tester can be used to collect the flow temperature、flow pressure and pressure recovery during the heavy oil thermal recovery, the data can guide the next thermal recovery.

Technical parameters:

1、measuring range:  temperature 0 ℃ ~ 350 ℃;  pressure 0 MPa  ~ 35 MPa

2、measuring accuracy: ±1 ℃;  Pressure ±0.1%

3、Sampling interval: 1 s(min、hour) to 60 s(min、hour)

4、downhole working time: ≤200 days (temperature 250 ℃)

5、Overall dimensions: φ73 mm ×2000 mm
